AFSB 132 — Hammer mill refiner 132 kW
Industrial refiner 132 kW, Ø1,000 mm chamber, 120 hammers, 2,800 kg/h. Designed for large-scale production with optimised energy consumption per ton.
Industrial
Free study and quote
Every machine is sized to your materials, volumes and site constraints. Reply within 24 to 48 business hours.
Key features
- Adjustable granulometry from 0.5 to 12 mm by screen change
- Tungsten carbide hammers for extended lifespan
- High-strength 65Mn steel screen
- High-speed rotor (2,980 rpm, 102 m/s) for optimal refining
- Robust design for intensive operation
- Compatible with cyclone, rotary valve and filter sleeves
Specs
Technical specifications
PropertyValue
Motor power132 kW
Throughput2 700 kg/h
Number of hammers120
Diamètre chambre de broyageØ 1 000 mm
Output granulometry0,5 – 12 mm (selon grille)
Vitesse rotor2 980 tr/min
Vitesse linéaire102 m/s
Matériau marteauxCarbure de tungstène
Matériau grilleAcier 65Mn
